STM32F103ZET6 Industrial Control Board

This compact industrial controller combines an STM32F103ZET6 Cortex-M3 MCU with isolated field I/O, multiple industrial communication interfaces and flexible analog and motion-control resources. It is suitable for automation equipment, data acquisition, distributed I/O, motion control and custom machine-control projects.

Communication Interfaces

2 isolated RS485 channels, with isolated signal and power
1 isolated CAN channel, with isolated signal and power
1 RS232 interface
USB-to-serial interface
TTL serial header and SWD programming/debug interface

I/O and Analog Resources

40 isolated digital inputs: 24 NPN inputs and 16 NPN/PNP configurable inputs
32 isolated digital outputs, including 8 high-speed isolated PWM outputs
8-channel 12-bit ADC acquisition supporting 0–10 V and 0–20 mA signals
2-channel 12-bit DAC output, 0–3.3 V
2 encoder inputs
16 MB W25Q128 external flash

Industrial Design

7–24 V DC input power
Operating temperature: −40 to 75 °C
Approximate standby power: 0.8 W
PCB dimensions: approximately 106 × 175 mm
Enclosure dimensions: approximately 200 × 110 × 60 mm
Industrial enclosure suitable for control cabinets and DIN-rail installations

Typical Applications

PLC-style control, production equipment, robotic workcells, remote I/O, sensor acquisition, servo and stepper control, test fixtures and customized automation systems.

Model: MCUBoard001
